EM-ONE
Beauty Value Creation
Resistance to Heat (Exposure Test)
Paint Adhesion Properties
(Cross Cut Test)
(Cross Cut Test)
Paint Adhesion Properties (T-Bend Test)
Resistance to Humidity (Cleveland Test)
Resistance to Corrosion (Salt Spray Test)
Resistance to Weathering (QUV Test)
Resistance to Colour Fading (QUV Test)
Resistance to Impact
(Reverse Impact test)
(Reverse Impact test)
Overview
EM-ONE pre-painted steel was developed by the Empower Steel using modern production system paint technology called Super Advance Durability Polyester (SADP), which contains pigments derived from “Natural minerals” to increase it’s efficiency with greater durability in different environments. EM-ONE incorporate auto clean technology to help the surface clean and bright. Empower Steel has also design an Em-Strip Film to protect the steel surface from scratches during processing, transportation and product installation. With Solar Reflectance technology, the colour are beautiful for longer. EM-ONE pre-painted steel reflect heat better than other manufactures as it is designed to be coated on various materials.
Product Idea
EM-Strip Film, Ultra-quality clear film Designed to be used with Empower Steel products to prevent scratches While transporting and installing So that the product’s skin is still as beautiful as new
Substrate
: Galvalume Steel (AZ150)
Galvanized Steel, Stainless Steel and Aluminium
Galvanized Steel, Stainless Steel and Aluminium
Material Grade
: G550, G300
Surface Treatment
: Chemical Conversion Coating
Top Coat
: Paint system : Super Advance
Durability Polyester 20 µm,
Corrosion Inhibitive Primer 5 µm
Durability Polyester 20 µm,
Corrosion Inhibitive Primer 5 µm
Backing Coat
: Paint system Modified Polyester 5 µm,
Corrosion Inhibitive Primer 5 µm
Corrosion Inhibitive Primer 5 µm
Strippable Film
: Em-Strip Film
Base Metal Thickness (BMT)
: 0.40, 0.42 mm. (Up to 1.20 mm.)
Width
: 914-1219 mm. (ฺUp to 1270 mm.)
Testing Method
| Properties | Test Mehod | Purpose | Standard | |
| Dry film Thickness | Dry film Thickness Measurement | Paint Thickness | TIS 2753 ASTM D5796 AS/NZS 1580.108.1 | |
| Paint Film Hardness | Pencil Hardness | Hardness properties of paint layer | TIS 2753 ASTM D3363 JIS G3322 | |
| Paint Adhesion | Cross Cut | Adhesion between paint layer | TIS 2753 JIS G3322 | |
| T-Bend | Colour adhesion and flexibility | TIS 2753 ASTM D4145 AS/NZS 2728 (App.F) JIS G3322 | ||
| Dupont Impact | Colour adhesion and flexibility | TIS 2753 JIS G3322 | ||
| Reverse Impact | Colour adhesion and flexibility | AS/NZS 2728 | ||
| Gloss | 60º Gloss Meter | Colour gloss | ASTM D523 AS/NZS 1580.602.2 | |
| Corrosion Resistance | Salt Spray Test (SST) | Corrosion resistant properties | TIS 2753 ASTM B117 |
More Testing Method
| Properties | Test Mehod | Purpose | Standard | |
| Weathering Resistance | ||||
| Chalking | QUV | Weather resistant properties | ASTM D4214 method D AS/NZS 1580.481.1.11 | |
| Colour Fading | QUV | Weather resistant properties | ASTM G154 ASTM D2244 | |
| Humidity Resistance | QCT (Cleveland) | Relative humidity resistance properties | ASTM D4585 / D4585M AS/NZS 1580.481.1.9 | |
| Solvent Resistance | Mechanical Rubbing (MEK) | Dryness of paint | ASTM D5402 or D7835/ D7835M | |
| Colour Shading | Light Source (Colour-Visual) | Colour difference | AS/NZS 1580.601.1 | |
| Colour Sectrophotometer (∆E) | Colour deviation | ASTM D2244 |
Product Warranty
- Non-peeling due to corrosion
- Flawlessness or flakes of colour
- The colour does not fade or flake severely.
- No alkaline cycle from dust accumulation
Substrate
: Galvalume Steel (AZ150)
Galvanized Steel, Stainless Steel and Aluminium
Galvanized Steel, Stainless Steel and Aluminium
Material Grade
: G550, G300
Surface Treatment
: Chemical Conversion Coating
Top Coat
: Paint system : Super Advance
Durability Polyester 20 µm,
Corrosion Inhibitive Primer 5 µm
Durability Polyester 20 µm,
Corrosion Inhibitive Primer 5 µm
Backing Coat
: Paint system Modified Polyester 5 µm,
Corrosion Inhibitive Primer 5 µm
Corrosion Inhibitive Primer 5 µm
Strippable Film
: Em-Strip Film
Base Metal Thickness (BMT)
: 0.40, 0.42 mm. (Up to 1.20 mm.)
Width
: 914-1219 mm. (ฺUp to 1270 mm.)
EM-Colour
Unity Green
RGB 36, 63, 51
HEX #243F33
CMYK 43, 0, 19, 75
RAL
Unity White
RGB 227, 233, 233
HEX #E3E9E9
CMYK 3, 0, 0, 9
RAL
Glory White
RGB 230, 229, 225
HEX #E6E5E1
CMYK 0, 0, 2, 10
RAL
Caramel Coffee
RGB 104, 62, 36
HEX #683E24
CMYK 0, 40, 66, 59
RAL
Unity Blue
RGB 58, 80, 96
HEX #3A5060
CMYK 39, 17, 0, 62
RAL
Unity Black
RGB 39, 37, 37
HEX #272525
CMYK 0, 5, 6, 85
RAL
Iron Grey
RGB 73, 73, 73
HEX #494949
CMYK 1, 0, 0, 71
RAL
Orange Stone
RGB 175, 102, 58
HEX #AF663A
CMYK 0, 42, 67, 31
RAL
Unity Grey
RGB 50, 52, 56
HEX #323438
CMYK 10, 6, 0, 78
RAL
Blue Paradise
RGB 0, 95, 110
HEX #005F6E
CMYK 100, 14, 0, 57
RAL
Cotton White
RGB 220, 216, 207
HEX #DCD8CF
CMYK 0, 2, 6, 14
RAL
Midnight Brown
RGB 108, 95, 82
HEX #6C5F52
CMYK 0, 12, 25, 58
RAL
Black Caviar
RGB 26, 26, 26
HEX #1A1A1A
CMYK 2, 0, 1, 90
RAL
Bricker Red
RGB 123, 56, 48
HEX #7B3830
CMYK 0, 54, 61, 52
RAL
Brilliant Blue
RGB 45, 60, 69
HEX #2D3C45
CMYK 35, 13, 0, 73
RAL
Silver Grey
RGB 148, 152, 150
HEX #949896
CMYK 2, 0, 1, 41
RAL
Storm Grey
RGB 73, 76, 80
HEX #494C50
CMYK 8, 5, 0, 69
RAL
Beige Base
RGB 225, 190, 159
HEX #E1BE9F
CMYK 0, 16, 29, 12
RAL
Brown Almond
RGB 210, 198, 168
HEX #D2C6A8
CMYK 0, 6, 20, 18
RAL
Military Green
RGB 83, 90, 82
HEX #535A52
CMYK 3, 0, 0, 9
RAL
Steel Grey
RGB 65, 76, 77
HEX #414C4D
CMYK 16, 0, 0, 70
RAL
