EM-DURA
Transcends The Ordinary
Resistance to Heat (Exposure Test)
Paint Adhesion Properties
(Cross Cut Test)
(Cross Cut Test)
Paint Adhesion Properties (T-Bend Test)
Resistance to Humidity (Cleveland Test)
Resistance to Corrosion (Salt Spray Test)
Resistance to Weathering (QUV Test)
Resistance to Colour Fading (QUV Test)
Resistance to Impact
(Reverse Impact test)
(Reverse Impact test)
Overview
EM-DURA pre-painted steel was developed by the Empower Steel. With advanced coating technology PVDF. EM-DURA pre-painted steel is resistant to UV light with heat reflecting properties and is well used in highly corrosive areas. EM-DURA incorporate auto clean technology to help the surface clean and bright for longer. It also designed and Em-Strip Film to protect the steel surface from scratches during processing, transportation and product installation. With Solar Reflectance technology, the colours are beautiful for longer. EM-DURA pre-painted steel reflect heat better than other manufactures.
Product Offer
EM-Strip Film, Ultra-quality clear film Designed to be used with Empower Steel products to prevent scratches While transporting and installing So that the product’s skin is still as beautiful as new
Substrate
: Galvalume Steel (AZ150)
Galvanized Steel, Stainless Steel and Aluminium
Galvanized Steel, Stainless Steel and Aluminium
Material Grade
: G550, G300
Surface Treatment
: Chemical Conversion Coating
Top Coat
: Paint system PVDF 22 µm,
Corrosion Inhibitive Primer 5 µm
Corrosion Inhibitive Primer 5 µm
Backing Coat
: Paint system PVDF 22 µm,
Corrosion Inhibitive Primer 5 µm
Corrosion Inhibitive Primer 5 µm
Strippable Film
: Em-Strip Film
Base Metal Thickness (BMT)
: 0.40, 0.42 mm. (Up to 1.20 mm.)
Width
: 914-1219 mm. (ฺUp to 1270 mm.)
Testing Method
| Properties | Test Mehod | Purpose | Standard | |
| Dry film Thickness | Dry film Thickness Measurement | Paint Thickness | TIS 2753 ASTM D5796 AS/NZS 1580.108.1 | |
| Paint Film Hardness | Pencil Hardness | Hardness properties of paint layer | TIS 2753 ASTM D3363 JIS G3322 | |
| Paint Adhesion | Cross Cut | Adhesion between paint layer | TIS 2753 JIS G3322 | |
| T-Bend | Colour adhesion and flexibility | TIS 2753 ASTM D4145 AS/NZS 2728 (App.F) JIS G3322 | ||
| Dupont Impact | Colour adhesion and flexibility | TIS 2753 JIS G3322 | ||
| Reverse Impact | Colour adhesion and flexibility | AS/NZS 2728 | ||
| Gloss | 60º Gloss Meter | Colour gloss | ASTM D523 AS/NZS 1580.602.2 | |
| Corrosion Resistance | Salt Spray Test (SST) | Corrosion resistant properties | TIS 2753 ASTM B117 |
More Testing Method
| Properties | Test Mehod | Purpose | Standard | |
| Weathering Resistance | ||||
| Chalking | QUV | Weather resistant properties | ASTM D4214 method D AS/NZS 1580.481.1.11 | |
| Colour Fading | QUV | Weather resistant properties | ASTM G154 ASTM D2244 | |
| Humidity Resistance | QCT (Cleveland) | Relative humidity resistance properties | ASTM D4585 / D4585M AS/NZS 1580.481.1.9 | |
| Solvent Resistance | Mechanical Rubbing (MEK) | Dryness of paint | ASTM D5402 or D7835/ D7835M | |
| Colour Shading | Light Source (Colour-Visual) | Colour difference | AS/NZS 1580.601.1 | |
| Colour Sectrophotometer (∆E) | Colour deviation | ASTM D2244 |
Product Warranty
- Non-peeling due to corrosion
- Flawlessness or flakes of colour
- The colour does not fade or flake severely.
- No alkaline cycle from dust accumulation
Substrate
: Galvalume Steel (AZ150)
Galvanized Steel, Stainless Steel and Aluminium
Galvanized Steel, Stainless Steel and Aluminium
Material Grade
: G550, G300
Surface Treatment
: Chemical Conversion Coating
Top Coat
: Paint system PVDF 22 µm,
Corrosion Inhibitive Primer 5 µm
Corrosion Inhibitive Primer 5 µm
Backing Coat
: Paint system PVDF 22 µm,
Corrosion Inhibitive Primer 5 µm
Corrosion Inhibitive Primer 5 µm
Strippable Film
: Em-Strip Film
Base Metal Thickness (BMT)
: 0.40, 0.42 mm. (Up to 1.20 mm.)
Width
: 914-1219 mm. (ฺUp to 1270 mm.)
Colour
Shadow White
RGB 230, 229, 225
HEX #E6E5E1
CMYK 0, 0, 2, 10
RAL
Noble Grey
RGB 148, 152, 150
HEX #949896
CMYK 2, 0, 1, 41
RAL
Hickory Brown
RGB 104, 62, 36
HEX #683E24
CMYK 0, 40, 66, 59
RAL
Magma Red
RGB 123, 56, 48
HEX #7B3830
CMYK 0, 54, 61, 52
RAL
Sapphire Blue
RGB 0, 95, 110
HEX #005F6E
CMYK 100, 14, 0, 57
RAL
Dim Grey
RGB 73, 76, 80
HEX #494C50
CMYK 8, 5, 0, 69
RAL
Denim Blue
RGB 45, 60, 69
HEX #2D3C45
CMYK 35, 13, 0, 73
RAL
Pebble Grey
RGB 50, 52, 56
HEX #323438
CMYK 10, 6, 0, 78
RAL
Verona Green
RGB 36, 63, 51
HEX #243F33
CMYK 43, 0, 19, 75
RAL
